NVIDIA GeForce RTX 5070 Specifications
Core Specifications
-
GPU Model: GeForce RTX™ 5070
-
Core Clock:
-
Reference: 2512 MHz
-
Boost (OC Model): 2625 MHz (+113 MHz over reference)
-
-
CUDA Cores: 6144 (Significant upgrade over RTX 4070's 5888 cores)
Memory Configuration
-
Capacity: 12GB GDDR7
-
Memory Speed: 28 Gbps
-
Bus Width: 192-bit (Wider than RTX 4070's 192-bit but with faster GDDR7)
-
Effective Bandwidth: ~672 GB/s (Calculated: 28 Gbps × 192-bit ÷ 8)
Interface & Power
-
Bus Standard: PCIe 5.0 x16
-
PSU Recommendation: 750W (Suggests ~220-250W TDP)
-
Power Connector: 1x 16-pin (12V-2x6)
-
Included Adapter: 1x 12V-2x6 to 2x PCIe 8-pin
-
Display & Connectivity
-
Max Resolution: 8K (7680×4320)
-
Outputs:
-
3× DisplayPort 2.1b (Supports 8K@120Hz with DSC)
-
1× HDMI 2.1b (4K@144Hz, 8K@60Hz)
-
-
Multi-Monitor: Supports 4 displays simultaneously
Physical Design
-
Dimensions: 324mm (L) × 130mm (W) × 56mm (H)
-
Larger than RTX 4070 (324mm vs. ~240mm)
-
-
Form Factor: ATX (May require full-tower cases)
Software & APIs
-
DirectX: 12 Ultimate
-
OpenGL: 4.6
Included Accessories
-
Quick Guide
-
Warranty Registration Card
-
1x 12V-2x6 to 2x PCIe 8-pin Adapter
-
Versatile VGA Holder (GPU anti-sag bracket)
-
VGA Holder Manual
